TPE-P Layflat Flexible Pipe

Application: Suitable for use and recommended for flowback water transfer, mining dewatering, long-distance fresh water transfer.
Inner tube and cover: Smooth TPE-P cover and tube.
Reinforcement: Circular woven polyester jacket
Operating Temperature Range: From -60° F to 176° F (-50° C to 80° C)
Standard Color: Blue, black, other colors available per request
Standard Length: 300ft/91.5m, 330ft/100m, 660ft/200m; other lengths available per request;
Couplings: Storz couplings, Camlocks etc.
Availability:
Quantity:

ID

Wall Thickness

Weight

Working Pressure

Bursting Pressure

Inch

mm

Inch

mm

lbs/ft

kg/m

PSI/bar

PSI/bar

2”

52+1.5

0.10”

2.4

0.35

0.52

300PSI/21bar

900PSI/63bar

3”

77+2.0

0.10”

2.5

0.61

0.90

250PSI/17bar

750PSI/51bar

4”

104+2.0

0.13”

3.0

0.89

1.33

250PSI/17bar

750PSI/51bar

6”

155+2.5

0.15”

3.8

1.60

2.38

200PSI/14bar

600PSI/42bar

8”

204+3.0

0.17”

4.3

2.17

3.23

200PSI/14bar

600PSI/42bar
