| Quantity: | |
|---|---|
Metric Size | Inch Size | SAE Dash size | I.D | O.D | W.P | B.P | Bending Radius | Weight | ||
(mm) | (mm) | |||||||||
mm | Inches | Dash | Min | Max | Min | Mpa | Psi | Mpa | mm | Kg/m |
19 | 3/4 | 12 | 18.2 | 19.8 | 34.9 | 2.1 | 305 | 8.4 | 125 | 0.81 |
25 | 1 | 16 | 24.6 | 26.2 | 41.3 | 1.7 | 247 | 6.8 | 150 | 0.97 |
31.8 | 1-1/4 | 20 | 30.6 | 33.0 | 50.8 | 1.4 | 203 | 5.6 | 200 | 1.24 |
38 | 1-1/2 | 24 | 36.9 | 39.3 | 57.2 | 1.1 | 160 | 4.2 | 255 | 1.50 |
51 | 2 | 32 | 49.2 | 52.4 | 69.9 | 0.7 | 102 | 2.8 | 300 | 1.89 |
63 | 2-1/2 | 40 | 61.9 | 65.1 | 82.6 | 0.4 | 58 | 1.6 | 355 | 2.54 |
76 | 3 | 48 | 74.6 | 77.8 | 95.3 | 0.4 | 58 | 1.6 | 460 | 3.20 |
89 | 3-1/2 | 56 | 87.3 | 90.5 | 107.9 | 0.3 | 44 | 1.2 | 530 | 3.84 |
Metric Size | Inch Size | SAE Dash size | I.D | O.D | W.P | B.P | Bending Radius | Weight | ||
(mm) | (mm) | |||||||||
mm | Inches | Dash | Min | Max | Min | Mpa | Psi | Mpa | mm | Kg/m |
19 | 3/4 | 12 | 18.2 | 19.8 | 34.9 | 2.1 | 305 | 8.4 | 125 | 0.81 |
25 | 1 | 16 | 24.6 | 26.2 | 41.3 | 1.7 | 247 | 6.8 | 150 | 0.97 |
31.8 | 1-1/4 | 20 | 30.6 | 33.0 | 50.8 | 1.4 | 203 | 5.6 | 200 | 1.24 |
38 | 1-1/2 | 24 | 36.9 | 39.3 | 57.2 | 1.1 | 160 | 4.2 | 255 | 1.50 |
51 | 2 | 32 | 49.2 | 52.4 | 69.9 | 0.7 | 102 | 2.8 | 300 | 1.89 |
63 | 2-1/2 | 40 | 61.9 | 65.1 | 82.6 | 0.4 | 58 | 1.6 | 355 | 2.54 |
76 | 3 | 48 | 74.6 | 77.8 | 95.3 | 0.4 | 58 | 1.6 | 460 | 3.20 |
89 | 3-1/2 | 56 | 87.3 | 90.5 | 107.9 | 0.3 | 44 | 1.2 | 530 | 3.84 |
