PVC Clear Hose

Tube and Cover: PVC
PVC Clear Hose Application:PVC transparent hose is used for conveying water,oil,gas under normal working condition in factories,farm,ship,building and family.
PVC Clear Hose Characteristic:
●Flexible, light, transparent
●Food grade, non-toxic, without odor
●Anti-erosion and anti-abrasion
●Anti-aging, long working life
Temperature: -10℃(-50℉) to 65℃(+150℉)

Availability:

Quantity:



Inquire Add to Basket

Product Description

PVC Clear Hose non toxic, clear PVC wall allows full visual flow of materials, weathering resistant, and resistance to low pressure and erosion, smooth tube for resistance to collection or blockage. By adding colorful symbol lines on the surface of the hose, it looks more beautiful.

Inner Diameter		Outer Diameter		Weight	W.P.(at 23ºC)		Std Length
inch	mm	inch	mm	kg/m	bar	psi	m	ft
1/8	3	0.196	5	0.017	4	60	100	300
1/6	4	0.236	6	0.02	4	60	100	300
1/5	5	0.314	8	0.04	4	60	100	300
1/4	6	0.354	9	0.047	4	60	100	300
5/16	8	0.433	11	0.059	4	60	100	300
3/8	10	0.511	13	0.071	4	60	100	300
1/2	12	0.59	15	0.08	3	45	100	300
5/8	15	0.708	18	0.1	3	45	50	150
3/4	19	0.866	22	0.13	3	45	50	150
1	25	1.181	30	0.28	2	30	50	150
1-1/4	32	1.496	38	0.43	2	30	30	90
1-1/2	38	1.732	44	0.52	2	30	30	90
2	50	2.283	58	0.9	2	30	30	90

Food Grade PVC Clear Hose Flexible PVC Clear Hose
