Grandflex EPDM Food Suction and Delivery Hose is ideal for food transfer applications requiring both flexibility and durability. It features a clean white FDA - grade tube made of food - grade EPDM, which is odorless and suitable for transporting milk, fruit juices, soft drinks, beer, wine, pharmaceuticals, cosmetics, and other non - oily food products. The tube's high - temperature synthetic rubber compound adheres to 3 - A, USDA, and FDA food - handling standards. Its smooth bore maximizes flow rates and prevents bacterial growth. The hose's cover, crafted from corrugated gray nitrile, offers flexibility along with resistance to chemicals, heat, and aging. Reinforced by multiple textile spirals and a dual - wire helix, it ensures flexibility, strength, better coupling retention, and kink resistance. With a temperature range of - 90°F to + 176°F, it can be paired with various coupling options.
I.D | O.D | W.P | B.P | Length | ||||
inch | mm | mm | bar | psi | bar | psi | m | ft |
3/4" | 19.1 | 31 | 10 | 150 | 30 | 450 | 61 | 200 |
1" | 25.4 | 37 | 10 | 150 | 30 | 450 | 61 | 200 |
1-1/4" | 31.8 | 44 | 10 | 150 | 30 | 450 | 61 | 200 |
1-1/2" | 38.1 | 51 | 10 | 150 | 30 | 450 | 61 | 200 |
2" | 50.8 | 64 | 10 | 150 | 30 | 450 | 61 | 200 |
2-1/2" | 63.5 | 80 | 10 | 150 | 30 | 450 | 61 | 200 |
3" | 76.2 | 92 | 10 | 150 | 30 | 450 | 61 | 200 |
3-1/2" | 89 | 105 | 10 | 150 | 30 | 450 | 61 | 200 |
4" | 101.6 | 120 | 10 | 150 | 30 | 450 | 61 | 200 |
6" | 152 | 172 | 10 | 150 | 30 | 450 | 30.5 | 100 |
